NEU: Betonmischanlage SUMAB T-10 (10m3/h) ECONOMY CLASS

Stationary concrete plant SUMAB T-10. ECONOMY CLASS

Main data:

• Turbine type concrete mixer 375 liters of output of fresh vibrated inserted concrete;

• Construction type: in line hoppers 8 m3each;

• Coming construction for support;

• Height of overhang [exhaust] 2,5 m (or more by request);

• Nominal production of capacity of 15 m3/h of fresh vibrated inserted transporting concrete in continuous work (based on 60 sec continuous cycles);

• 3 types of aggregates;

• Weight dosing of cement, aggregates and liquid additives;

• Volumetric dosing of water;

Control by manual and automatic [by computer Siemens] with 100 different programs [different concrete mixtures];

BASIC TECHNICAL DATA OF PLANT

Model SUMAB T-10

Production capacity of wet concrete based on 30 sec mixing time 15 m3/h

Ambient oversea height Until 1.000 m

Ambient temperature for work -10 to 50 °C

Working temperature of machines inside of plant 5 to 35 °C

Maximum allowed wind 120 km/h

Power supply 380-420 V, 50 Hz [EC standard]

TECHNICAL DATA OF MIXER

Volume size of mixer’s drum 560 l

Output of fresh vibrated inserted concrete 375 l

Nominal production capacity of concrete 15 m3/h

Diameter of mixer’s drum 1550 mm

Maximum weight of concrete 800 kg

Engine power for mixer 11 kW

Engine power for hydraulics 1.5 kW

Output doors 1 pcs

Covering of bottom – thickness/quality 10 mm / Hardox 300

Covering of walls – thickness/quality 10 mm / Fe 520

Maximum size of aggregate 60 mm

Weight of mixer with skip 1 850 kg

Number of mixing hands 4 pcs

Number of scrapers 2pcs

Concrete plants SUMAB are a guarantee of quality, durability and reliability. Batching plant is produced on Scandinavian technology, using components from leading European manufacturers!

Scandinavian quality at the best price!

If you need more information, you can visit our website, or send a request. We'll necessarily find the best solution for you!
