Teleskopradlader New 5m Telescopic Loader MAXUS 5m

Trade Name: MAXUS

Engine

(1) Brand/Model: Yunnei YN33GBZ

(2) Type: Inline, water-cooled, four-cylinder, turbocharged diesel engine

(3) Rated Power: 90 HP

Optional Models:

EPA3 YANMAR engine; EPA3

CUMMINS engine; EPA4

2. General Dimensions

(1) Overall Length: 6500 mm

(2) Overall Width: 2000 mm

(3) Overall Height: 2860 mm

(4) Bucket Hinge Pin Height: 4500 mm

(5) Telescopic Stroke: 1100 mm

(6) Extended Arm Length: 2950 mm

(7) Maximum Bucket Lifting Height: 5100 mm

(8) Maximum Bucket Discharge Height: 4000 mm

3. Transmission System

Gearbox + Hydraulic Torque Converter + Drive Shaft + Hub Reducer

4. Bucket

(1) Volume: approximately 1 m³

(2) Width: approximately 2000 mm

(3) Type: Reliable threaded coupling with teeth

Maximum Load: 2000 kg, including bucket or attachments

5. Operational Specifications

Steering: Hydraulic articulated steering

Drive: Four-wheel drive

Hydraulic Quick Coupler: Yes

Mechanical Joystick: Yes

Constant Lifting: Yes

6. Brake System

(1) Main Brake: Disc brake on all four wheels

(2) Parking Brake: Disc brake

7. Tires

(1) Model: 16/70-20 Chevron pattern tire

(2) Size: Width 380 mm, Diameter 1075 mm

8. Wheelbase: 2550 mm

9. Track Width: 1600 mm

10. System Working Pressure: 20 MPa

11. Weight: 5500 kg
